Specification |
Model No. L812P
|
Image Sensor |
Image Sensor |
1/4" CMOS Sensor |
Display Resolution |
720P (1280*720P) |
Lens |
f:6mm, F:2.0, Built-in IR Fliter |
Minimum Lux Required |
0.5lm for Normal Operation |
Lens |
Lens Type |
Glass Lens |
Viewing Angle |
60degree |
Audio |
Input |
Built-in Microphone / One Channel Audio Input |
Output |
One Channel Audio Output |
Audio Compression |
ADPCM |
Video |
Image Compression |
H.264 |
Image Frame Rate |
20fps(720P), 30fps(QVGA) |
Resolution |
1280x720 (720P), 640x480(VGA), 320x240(QVGA) |
Flip Mirror Images |
Vertical / Horizontal |
Frequency |
50Hz, 60Hz, Outdoor |
Video Parameters |
Brightness, Contrast |
Communication |
Ethernet Interface |
Built-in 10/100Mbps, Auto MDI/MDIX, RJ-45 |
Supported Protocol |
HTTP, FTP, TCP/IP, UDP, SMTP, DHCP, PPPoE, DDNS, UPnP, GPRS |
Wireless Standard |
IEEE 802.11b/g |
Data Rate |
802.11b: 11Mbps(Max.), 802.11g: 54Mbps(Max.) |
Wireless Security |
WEP & WPA WPA2 Encryption |
Physical |
Pan/Tilt Angle |
Pan: 350-Degree, Tilt: 120-Degree |
Alarm Input |
One Channel On/Off Iutput |
Alarm Input |
One Channel Relay Output |
Infrared Light |
LED Illuminators for Night Vision |
Power |
Power Supply |
DC12V/2.0A |
Power Consumption |
7 Watts (Max.) |
Environment |
Operating Temp. |
0℃ - 55℃(14°F - 131°F) |
Operating Humidity |
20% - 85% Non-Condersing |
Storage Temp. |
-10℃ - 60℃(14°F - 140°F) |
Storage Humidity |
0% - 90% Non-Condersing |
PC Requirements |
CPU |
2.0GHZ or Above (Suggested 3.0GHz) |
Memory |
256MB or Above (Suggested 1.0GB) |
Display Card |
64M or Above |
Supported OS |
Microsoft Windows XP/Vista/7/8 |
